Hệ thống Live Production TriCaster TC1

16 Input External đồng thời: Hỗ trợ nhận tối đa 16 nguồn vào từ bất kỳ sự kết hợp nào của NDI, SDI (qua bo mạch vật lý hoặc các module mở rộng Spark) ở mọi độ phân giải lên đến 4K UHD 60p.
Xử lý 4K UHD không thỏa hiệp: Khác với các dòng máy cũ phải giảm số lượng input khi bật chế độ 4K, TC1 cho phép bạn sử dụng cả 16 input ở độ phân giải 4K UHD 60p mà không bị giới hạn hiệu năng.
4 M/E Buses (Mix/Effects): Mỗi M/E bus hỗ trợ cấu hình lên đến 4 nguồn vào (sources) và 4 lớp kĩ xảo (KEY layer), giúp xây dựng các phân cảnh phức tạp, tái hiện các trường quay ảo (Virtual Sets) đa góc máy cực kỳ chân thực.
2 Kênh Livestream độc lập: Tích hợp sẵn bộ mã hóa kép (Dual-channel streaming encoder), cho phép phân phối luồng trực tiếp đồng thời lên hai nền tảng khác nhau (như Facebook Live, YouTube, Twitch…) với cấu hình riêng biệt.
Ghi hình đa kênh mã hóa (IsoCorder): Khả năng ghi hình đồng thời tối đa 4 kênh dữ liệu chất lượng cao (QuickTime hoặc H.264) từ bất kỳ nguồn input hoặc output nào phục vụ cho công tác lưu trữ hoặc hậu kỳ trực tiếp.
Xuất xứ: Mỹ
Chế độ bảo hành: 1 năm

Danh mục: Pro video, Trường quay ảo Thương hiệu: Virzt (USA)

Mô tả
Đánh giá (0)

THÔNG SỐ KỸ THUẬT

Category	Technical Specification
Video Input	16 x simultaneous external video inputs, supporting any combination of compatible sources in resolutions up to 4K UHD at frame rates up to 60fps (2160p 59.94)
SDI Video Input1	4 x 3G/HD/SD-SDI connections supporting video input in any combination of standard formats, resolutions, and frame rates²1080p: 59.94, 50, 29.97, 25 – 1080i: 59.94, 50 – 720p: 59.94, 50, 29.97, 25 – 576i 50 – 480i 59.94 ¹Optionally supports up to 16 simultaneous 3G/HD/SD-SDI video inputs or quad-link 3G-SDI video inputs (4K UHD) via network integration with applicable NewTek NC1 conversion modules ²Available frame rates determined by session video standard (NTSC or PAL)
PTZ	Support for up to 8 simultaneous Pan-Tilt-Zoom (PTZ) robotic cameras via serial and network protocols, including RS232, RS422 and IP, with integrated controls and preset system
Skype TX	Native support for up to 2 simultaneous Skype® video call inputs via Skype TX software integration, including tally and Talk Back communication
Video Output	Configurable for up to 4 independent video mix outputs, with simultaneous delivery via IP and SDI
Network Video Output	IP video output via NDI, optionally configurable for: – 4 x independent video mix outputs – 1 x 4K UHD video mix output
SDI Video Output	4 x 3G/HD/SD-SDI connections, optionally configurable for: – 4 x independent 3G/HD/SD video mix outputs – 1 x 4K UHD video mix output via 3G-SDI quad-link grouping
Stream Output	2 x resolution-independent streaming video outputs, independently configurable, with simultaneous stream archive
Multiviewer Output	3 x multiviewer outputs supporting standard display resolutions – 1 x DisplayPort (v1.4a) – 2 x HDMI™ (HDMI™ v2.1)
Mix/Effect Buses (M/E)	4 x M/E buses supporting video re-entry – 1 x Mix/Effect channel per bus with support for up to 4 sources – 4 x KEY layers per bus – 9 x memory slots per bus – 1 x PREVIZ configuration and preview bus
DSK Channels	4 x DSK channels
Media	5 x media players – 2 x DDR – 2 x GFX – 1 x Sound – 15 x media buffers – 10 x animation buffers – 5 x graphic buffers 30 x clip players (available for use as transitions or media depending on function)
Keyers	Integrated LiveMatte™ chroma and luma keying technology on all source channels and M/E buses – 16 x input keyers – 4 x media player keyers – 4 x M/E keyers – 1 x PREVIZ keyer – 15 x buffer keyers
COMPs	Integrated video composition engine on the switcher and each M/E bus to create, store, and apply layer configurations and DVE-style motion sequences – 16 x configurable COMP presets per bus
Virtual Sets	Integrated LiveSet™ technology with 30+ live virtual sets and box effects included
DataLink	Integrated DataLink™ technology enabling real-time, automated data input from internal and external sources, including webpages, spreadsheets, scoreboards, databases, RSS feeds, watch files, XML, CSV, ASCII and more
Macros	Record, store, edit and automate commands and user-configured operation sequences – Attach to control panel buttons, keyboard shortcuts, hotspots, MIDI and X-keys® buttons or GPI triggers – Attach to internal events and state changes, including audio, media playback, tally and specific switcher actions – Supports control via web-based interface
Recording	8 x configurable video recording channels via IsoCorder™ technology – 8 x NDI® recordings (scalable to higher number with Premium Access) – 4 x QuickTime® archival video recorders (SHQ2 quicktime codec, 4:2:2 encoding, 24-bit audio, with timecode)³ – 2 x H.264 IsoCorder™ distribution video recorders (multiple profiles) ³QuickTime Player not required for playback in common NLE applications
Storage	2TB internal media storage – 2 x 2TB Media Drive – Capacity varies by format, resolution and file specification – Supports recording to external storage via USB 3.0 and eSATA – Supports shared storage integration and third-party partner solutions
Grab	Grab full-resolution, deinterlaced still images from external video sources and outputs
Export	Export video and image files to social media, FTP, local or external volumes, and network servers, with optional transcoding
Audio Mixer	Integrated multi-channel audio mixer with support for quad-channel audio, DSPs and 4x4x4 audio input routing
Local Audio Input	4 x SDI embedded 1 x Balanced XLR stereo pair (Line) 3 x Balanced 1/4” stereo pairs (Line)
Local Audio Output	– 4 x SDI embedded – 1 x Balanced XLR stereo pair – 1 x Balanced 1/4” stereo pair – 1 x Stereo 1/4″ (phones)
Network Audio	– Native support for network audio input and output via NDI – Embedded audio supported for all NDI input and output video signals – Integrated support⁴ for Dante™ networking protocol from Audinate® – Support for AES67 protocol via compatible WDM audio drivers⁵ ⁴Requires Dante Virtual Soundcard license from Audinate (sold separately) ⁵Requires third-party virtual sound card license (sold separately)
Supported Media File Formats	Import, store, and play back multimedia files, with optional transcoding, including: – Video: AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG, MP4, WMV, WebM, and more – Image: PSD, PNG, TGA, BMP, JPEG, JPEG-XR, JPEG2000, EXR, RAW, TIF, WebP, and more – Audio: AIFF, MP3, WAV, and more
Monitoring	Support for up to 3 multiviewer displays with configurable workspaces and viewports
Signal Monitoring	Integrated waveform and vectorscope, full field rate with digital calibration, color preview and support for ITU-R Rec. 709
Processing	– Video: YCbCr + Alpha color space, using 4:2:2:4 – Audio: Floating Point, 96 kHz
Latency	Processing Latency: ~1.0-1.5 frames
A/V Standards	– 4K UHD video conforms to SMPTE 2036 (UHDTV1 using Square Division Quad Split) – 3G-SDI video conforms to SMPTE 424M (Level A) – HD-SDI video conforms to SMPTE 292M – SD video conforms to SMPTE 259M and ITU-R BT.656 – Analog audio levels conform to SMPTE RP-155
Tally	Support for hardware tally via HD15 GPI connector, network tally via NDI, and Blackmagic Design® SDI tally standard
Genlock	Genlock input supporting SD (Bi-level) or HD (Tri-level) reference signals
GPI	Supports GPI signals via JLCooper Electronics eBox GPI interface
MIDI	Support for standard MIDI protocol enabling third-party device control
System Drive	250GB SSD
NIC	– 1 x 10 Gigabit LAN – 1 x 2.5 Gigabit LAN – 1 x 1 Gigabit LAN
USB	Front: – 2 x USB 3.0 Type-A Rear: – 2 x USB 2.0 Type-A – 5 x USB 3.2 Gen2 Type-A – 1 x USB 3.2 Gen2x2 Type-C
System Physical	2RU chassis with 500W PSU and multi-tiered hardware and software fail-safe – 19.0 x 3.5 x 19.57 in (48.3 x 8.9 x 49.7 cm) with rack ears attached
